Rincian produk
Tempat asal: Cina
Nama merek: AFK
Sertifikasi: PCE
Nomor model: DIN477
Syarat Pembayaran & Pengiriman
Kuantitas min Order: 1
Harga: dapat dinegosiasikan
Kemasan rincian: Karton
Waktu pengiriman: 1 MINGGU
Syarat-syarat pembayaran: L / C, D / A, D / P, T / T, Western Union, MoneyGram
Menyediakan kemampuan: 1000 pc
Bahan: |
Baja Tahan Karat, 316L, Baja Tahan Karat 304 atau 316, Baja Tahan Karat 304 316L |
UKURAN: |
1/4" OD x 1/4 NPT Pria |
Sedang: |
Gas |
Jaminan: |
1 tahun |
Teknik: |
Ditempa |
Koneksi: |
Perempuan, dilas |
Bahan: |
Baja Tahan Karat, 316L, Baja Tahan Karat 304 atau 316, Baja Tahan Karat 304 316L |
UKURAN: |
1/4" OD x 1/4 NPT Pria |
Sedang: |
Gas |
Jaminan: |
1 tahun |
Teknik: |
Ditempa |
Koneksi: |
Perempuan, dilas |
| KonfigurasiNomor barang | Sambungan Silinder | Benang | Panjang | Peringkat Tekanan |
| 009 | BS341 No.3 (Entri Basis) | 1/4” NPT Pria | 95mm-101mm/3,75”-4,00” | 250 bar / 3625 PSI |
| 010 | BS341 No.3 | 1/4” NPT Pria | 95mm-101mm / 3,75”-4,00” | 250 bar / 3625 PSI |
| 011 | BS341 No.4 (Entri Basis) | 1/4″ NPT Jantan | 67mm/2,625” | 250 bar/3625 PSI |
| 012 | BS341 No.4 | 1/4” NPT Pria | 95mm-101mm/3 75”-4,00” | 250 bar/3625 PSI |
| 013 | BS341 No.6 | 1/4” NPT Pria | 95mm-101mm/3 75”-4,00” | 250 bar / 3625 PSI |
| 014 | BS341 No.7 | 1/4″ NPT Jantan | 95mm-101mm/3 75”-4,00” | 250 bar/ 3625 PSI |
| 015 | BS341 No.8 | 1/4″ NPT Jantan | 95mm-101mm/3 75”-4,00” | 250 bar/ 3625 PSI |
| 016 | BS341 No.10 | 1/4″ NPT Jantan | 95mm-101mm/3 75”-4,00” | 250 bar/3625 PSI |
| 017 | BS341 No 11 | 1/4″ NPT Jantan | 95mm-101mm/3 75”-4,00” | 250 bar 7 3625 PSI |
| 018 | BS341 No.13 | 1/4″ NPT Jantan | 95mm-101mm/3 75”-4,00” | 50 bar/725 PSI |
| 019 | BS341 No 14 | 1/4″ NPT Jantan | 95mm-101mm/3 75”-4,00” | 250 bar/3625 PSI |
| 020 | BS341 No.15 | 1/4″ NPT Jantan | 95mm-101mm/3 75”-4,00” | 250 bar 7 3625 PSI |
| 021 | BS341 No30 | 1/4″ NPT Jantan | 95mm-101mm/3 75”-4,00” | 300 bar/4350 PSI |
| 022 | BS341 No 31 | 1/4″ NPT Jantan | 95mm-101mm/3 75”-4,00” | 300 bar/4350 PSI |
| 023 | BS341 No32 | 1/4″ NPT Jantan | 95mm-101mm/3 75”-4,00” | 300 bar 74350 PSI |
| 024 | BS341 No 38 | 1/4″ NPT Jantan | 95mm-101mm/3 75”-4,00” | 300 bar/4350 PSI |
| 025 | DIN 477 No.1 | 1/4″ NPT Jantan | 95mm-101mm/3 75”-4,00” | 300 bar/4350 PSI |
| 026 | DIN 477 No.2 | 1/4″ NPT Jantan | 95mm-101mm/3 75”-4,00” | 300 bar/4350 PSI |
| 027 | DIN 477 No.3 | 1/4″ NPT Jantan | 95mm-101mm/3 75”-4,00” | 25 bar/360PSI |
| 028 | DIN 477 No 31 | 1/4″ NPT Jantan | 95mm-101mm/3 75”-4,00” | 25 bar/360PSI |
| 029 | DIN 477 No.5 | 1/4″ NPT Jantan | 95mm-101mm/3 75”-4,00” | Lihat Standar DIN 477 |
| 030 | DIN 477 No.6 | 1/4″ NPT Jantan | 95mm-101mm/3 75”-4,00” | 300 bar/4350 PSI |
| 031 | DIN 477 No.7 | 1/4″ NPT Jantan | 95mm-101mm/3 75”-4,00” | Lihat Standar DIN 477 |
| 032 | DIN 477 No.8 | 1/4″ NPT Jantan | 95mm-101mm/3 75”-4,00” | Lihat Standar DIN 477 |
| 033 | DIN 477 No.9 | 1/4″ NPT Jantan | 95mm-101mm/3 75”-4,00” | 300 bar/4350 PSI |
| 034 | DIN 477 No.10 | 1/4″ NPT Jantan | 95mm-101mm/3 75”-4,00” | 300 bar/4350 PSI |
| 035 | DIN 477 No.11 | 1/4″ NPT Jantan | 95mm-101mm/3 75”-4,00” | Lihat Standar DIN 477 |
| 036 | DIN 477NO.12 | 1/4″ NPT Jantan | 95mm-101mm/3 75”-4,00” | Lihat Standar DIN 477 |
| 037 | DIN 477NHAI.13 | 1/4″ NPT Jantan | 95mm-101mm/3 75”-4,00” | 300 bar/4350 PSI |
| 038 | DIN 477 NO 14 | 1/4″ NPT Jantan | 95mm-101mm/3 75”-4,00” | 300 bar/4350 PSI |
| 039 | CGA170 | 1/4″ NPT Jantan | 95mm-101mm/3 75”-4,00” | 207 bar/3000PSI |
| 040 | CGA180 | 1/4″ NPT Jantan | 95mm-101mm/3 75”-4,00” | 207 bar/3000PSI |
| 041 | CGA280 | 1/4″ NPT Jantan | 95mm-101mm/3 75”-4,00” | 207 bar/3000PSI |
| 042 | CGA290 | 1/4″ NPT Jantan | 95mm-101mm/3 75”-4,00” | 34 5 bar/500 PSI |
| 043 | CGA296 | 1/4″ NPT Jantan | 95mm-101mm/3 75”-4,00” | 207 bar/3000PSI |
| 044 | CGA300 | 1/4″ NPT Jantan | 95mm-101mm/3 75”-4,00” | 34 5 bar/500 PSI |
| 045 | CGA320 | 1/4″ NPT Jantan | 95mm-101mm/3 75”-4,00” | 207 bar/3000PSI |
| 046 | CGA326 | 1/4″ NPT Jantan | 95mm-101mm/3 75”-4,00” | 207 bar/3000PSI |
| 047 | CGA330 | 1/4″ NPT Jantan | 95mm-101mm/3 75”-4,00” | 207 bar/3000PSI |
| 048 | CGA346 | 1/4″ NPT Jantan | 95mm-101mm/3 75”-4,00” | 207 bar/3000PSI |
| 049 | CGA350 | 1/4″ NPT Jantan | 95mm-101mm/3 75”-4,00” | 207 bar/3000PSI |
| 050 | CGA510 | 1/4″ NPT Jantan | 95mm-101mm/3 75”-4,00” | 34,5 bar/500 PSI |
| 0S1 | CGA520 | 1/4″ NPT Jantan | 95mm-101mm/3 75”-4,00” | 345 bar/500PSI |
| 052 | CGA540 | 1/4″ NPT Jantan | 95mm-101mm/3 75”-4,00” | 207 bar/3000PSI |
| 053 | CGA580 | 1/4″ NPT Jantan | 95mm-101mm/3 75”-4,00” | 207 bar/3000PSI |
| 0M | CGA590 | 1/4″ NPT Jantan | 95mm-101mm/3 75”-4,00” | 207 bar/3000PSI |
| 055 | CGA660 | 1/4″ NPT Jantan | 95mm-101mm/3 75”-4,00” | 207 bar/3000PSI |
| 056 | CGA705 | 1/4″ NPT Jantan | 95mm-101mm/3 75”-4,00” | 207 bar/3000PSI |
